Description
*** BRAND NEW FEAUTURES! ***
- KX-2 Heavy Load Gripper – This brand new gripper can lift up to 1 kilogram of weight, perfect for moving heavy deep well plates.
- KX-2 Dual Gripper – Double your throughput with the dual gripper attachment, allowing for the arm to grab a plate, flip around, and grab another plate in a matter of seconds.
- KX-2 Blended Motion – A new controller update now allows for smarter and smoother motion.
These features are available on the standard KX-2 or the NEW! Inverted KX-2
- The Inverted KX-2 – An innovative solution to clear valuable deck space in your lab! The inverted KX-2 robot hangs from above your workspace.
***********************************************************************************************
KX-2 COLLABORATIVE ROBOT FEATURES
- Flexible
With 360° continuous rotation of the shoulder and wrist axes and a multi-link arm, the KX-2 offers extensive reach for effective use of the available space. The radial compactness of the KX-2 arm, combined with a wide reach, allows easy instrument accessibility and optimal instrument placement, leading to improved instrument density, easy serviceability and increased throughput.
- Easy to decontaminate
The KX-2 was developed with contamination minimization in mind. The sealed design is wipe-clean with no bug traps, making it well-suited for Biosafety Level 2 applications.
- High Safety
The KX-2 is ideal for use on an open bench as operator safety is assured – the KX-2 stops safely on human contact. The fully enclosed working mechanism ensures finger protection, making the robot fundamentally safe to use. The KX-2 is fully compliant with safety standards: ISO 10218–1:2011.
- Simple to set up and easy to use
The KX-2 can handle a wide range of labware from different types of plates to tip racks, tube racks, petri-dishes and T-flasks, making it the robot of choice for a variety of research applications, including synthetic biology, drug discovery and biotechnology. The counter-balanced arm of the KX-2 allows handling of full deep well plates at maximum extension for optimal use of the work envelope.
KX-2 LINEAR RAIL FEATURES
- High Speed
A maximum speed of 0.75 m/s allows the linear rail to move quickly from one end of a large system to the other, increasing efficiency.
- Quiet Operation
The helical planetary gearing and belt drive keeps audible noise to a minimum.
- Drag-to-Teach
Simply move the linear rail and robot to the correct position and with a touch of a button and the teaching is complete. Quick, simple, and revolutionary.
- Intelligent Motion Control
The linear rail and robot execute synchronized motion simultaneously. This improves efficiency and simplifies setup.
- Easy to Integrate
USB interface provides easy connection to host PC. Linear rail and KX2 can be added to existing systems, expanding capability and throughput.
- Standard I/O built-in
Digital and Analogue I/O available at the linear rail connector panel for interfacing and controlling other devices.
- Numerous Options
Every application is unique and with a wide selection of options including linear rail length and various KX2 robot options, the linear rail and robot can be tailored to your exact requirements.
