KX-2 Laboratory Robot

Continuous 360 Rotation Cobot for Labware

When considering Safety, flexibility, and reliability, look no further than the KX-2. The KX-2 offers continuous 360 degree rotation on the shoulder and wrist axes, providing process optimization and increased throughput.
The full enclosure design makes it intrinsically safe and proven technology delivers reliable performance for all your automation needs.

Planar Conveyors

Autonomous cart levitating Planar conveying systems

Tek Matic offers an Autonomous Levitating Planar system. This free moving platform offers maximum flexibility while taking up minimum space in a facility. The ALP can be used in dirty, wet or clean environments. The ALP allows for complete freedom and flexibility in a workspace.

Miniature 6 Axis Robot

Industrial robotics in the palm of your hand

The Meca500 is the world’s smallest, most compact and most precise six-axis industrial robot arm. Its unrivaled precision and accuracy guarantee reliability in automating micropositioning tasks and delicate manipulations.

Custom Motors

Since 1983, Tek-Matic has been providing standard & custom motors for OEM manufacturers. We have provided solutions ranging from the world’s smallest piezomotors for precision optics to vertical spindle induction motors rated at thousands of HP. Motors can be designed to operate in challenging environments, such as ultra high vacuum, washdown & even MRI magnetic chambers. We look forward to learning about your custom motor requirements & designing you the perfect solution.

Smart Motors

Smart motor control for smarter machines

Save space, time and money by eliminating wires, cables and control panels by using smart motor technologies from Tek-Matic. Motion control systems typically consist of a motor with feedback, a drive/amplifier, and a smart controller. While motors are mounted to your machine, the drives/amplifiers are typically located inside of a remote panel, and then attached to each other via cable sets. These cables can be hard to make or source, time consuming to install, a source for noise (requiring troubleshooting), and can physically interfere with the motion itself Control panels can be expensive, take up extra space, and take time to build.

Smart motors are available with the motor/feedback/drive & controller all in one motor housing. Smart motors even have built in I/O logic, and communication protocols, sometimes eliminating the need for a PLC.

Optical Positioning Systems

Miniature positioners for optics manipulation

Optical position systems require special miniature motors and motion modules. SWaP, (Size, Weight, and Power) are very important factors along with precision positioning accuracy and position stability. These optronics solutions are used for autofocus, pan, tilt, shutter, and filter changing applications in both the defense and precision instrument markets.

Robotic Positioning Components

Positioners for patients and optics

Tekmatic has an extensive offering of precision positioning products used for motion control in a variety of life science instruments and systems. These include solutions from heavy duty actuators and gantry products used for patient therapy systems, to some of the world’s smallest piezo positioning products for optics in clinical and research diagnostic instruments.

Drive & Control

Nanomotion’s XCD – Drive & Control redefines the art of miniaturized drive and control electronics with the smallest hardware for operating piezo ceramic servo motors. The XCD provides complete servo control for the OEM market, coupled with the power stage and drive electronics on one board.

Rack & Pinion

Precision rack & pinion positioning systems

We offer a complete range of Rack & Pinion Drive Systems, which consist of a servo reducer with a mounted pinion on the output and the driven gear rack. By selecting the complete drive system all at once, a system can be optimized for the servo motor while achieving the desired accuracy and motion at the rack & pinion.

Precision Gearboxes

Precision gearboxes for servos & steppers

Servo gearheads and gearboxes are used on high precision motion control applications which require a high torque to volume ratio, high torsional stiffness, and low backlash. All of our gearheads are self-lubricating and have high radial load capacity for any given size. The ability to match inertias with our large variety of ratios keeps servo systems controlled and stable.

Servo & Stepper Motor Systems

Positioning motors, drives and controllers

Tek-Matic is a provider of precision rotary motion control systems including stepper, servo and high torque direct drive technologies. From the world’s smallest NEMA 11 steppers, to high speed/ precision closed loop servos, we have the system for you.

Ballscrews & Rails

Mechanical positioning components

Ballscrews offer a great way to convert rotational motion to linear motion with a minimal amount of friction. Precision rail guides are highly accurate products for linear motion and are ideally suited for use in a wide variety of machine tools, handling systems and special machinery, as well as in measuring and testing equipment, semi-conductor production machines and medical applications.

Positioning Stages & Slides

Mechanical actuator driven positioners

Tek-Matic offers one of the widest ranges of precision positioning stages and slides. Standard configurations include a variety of drive mechanisms, bearing supports, orientations, and environments. A wide range of pricing options from economy to ultra positioning accuracies are available. Custom units and assemblies can be provided.

Actuators

Linear electric positioners

Electric actuators are more cost-effective than their hydraulic and pneumatic counterparts. Electric actuators benefit from cleaner, simpler, and more energy-efficient power transmission. Electric actuator integration is easier with programmable controls, and maintenance is minimized with no parts replacement or lubrication needed except in extreme conditions.

EdgeScout

Remote Monitoring for Machines & Systems

EdgeScout offers a comprehensive industrial remote monitoring system that can maximize production, reduce operating costs and keep your equipment up and running. Manage machine and equipment performance and make real-time decisions from your desktop or mobile device anytime, anywhere.

Industrial Communication Technologies

Cutting edge industrial networking solutions

Take a look at Tek-Matic’s state-of-the-art industrial networking equipment ranging from Ethernet switches and PoE devices to industrial wireless and serial communication devices. Tek-Matic’s communication products support industry standards, are affordable, and perform efficiently in rugged environments.

Industrial Data Security

Industrial Control System Security

Defender products are designed to provide a layer of protection from standalone computers to full scale control systems. Keeping unwanted or non-designated devices such as USB flash drives, tethered phones, wireless devices from being plugged into or accessed by a standalone PC at the edge, providing safe and secure remote access, controlling supplier access to equipment, deep packet inspection of industrial protocols, network address translation, and a host of other capabilities are all a part of the Defender Defense-in-Depth strategies we offer our customers.

Factory floor displays

Large format Industrial Andon Systems

We offer one of the broadest ranges of factory floor Andon display systems. Sizes range from 32 to 150 inches and are all manufactured in the USA. You can now reliably display and transmit important OEE data.

Panel PC’s and Monitors

Industrial panel mount pcs and displays

A wide variety of panel mounted PC’s and monitors from 8 to 24 inches diagonally. Touch and non-touchscreen versions are available. Enclosure ratings include IP65, IP67, NEMA 4/4X. These units can directly fit into the cutout of PanelView+, Versaview, and Simatics units.

Simple Save

A simple and fast energy savings program for industrial manufacturers

Simple Save by Tek-Matic is a simple energy savings program that has extremely fast payback and requires barely any of your time and resources to implement. Simple Save benefits companies that have fans or pumps and are looking for reductions in energy usage and costs.

Integrated PLC, HMI, Touchscreen

Programmable Logic Controller (PLC) Solutions

Our Programmable Logic Controller (PLC) products are based around our Operator Control Station (OCS) concept and are used in all areas of automation. OCS combines a Controller, Operator Interface, Network and I/O into a single product.

Dedicated HMI Touchscreen

Industrial touchscreen HMI products

Interact Xpress(TM) is Parker CTC’s new Distributed HMI solution, featuring an advanced development environment for easy creation of rich graphics and multimedia applications. Xpress revolutionizes Level 1 HMI by allowing you to run, view and edit applications in any Internet Explorer(TM) browser. This architecture is ideal for distributed applications where multiple HMI’s are deployed on a single machine or across several remote stations.

Sensors & Vision Systems

Industrial sensors and vision camera systems

Tekmatic participates in the development, production and marketing of optoelectronic sensors and image-processing vision sensors for factory and lab automation. We also offer inductive, capacitive and ultrasonic sensors. These products are used in numerous applications and sectors from automotive and machine construction, through the electronics and solar industries, to the food and pharmaceutical industries.

Gearboxes & Gearmotors

Industrial rotary gearing systems

Since 1983, Tekmatic has been offering industrial gearbox and gearmotors solutions for some of the most rigorous applications including conveyors, pumps, solar and wastewater. Choose from several configurations such as right angle or inline, a variety of output shafts, and gearing technologies.

Variable Frequency Drives

(VFD)'s for motor speed control

Designed for variable speed control of all asynchronous motors and permanent magnet motors, on any industrial machine or production line, a VLT® AutomationDrive helps its owner save energy, increase flexibility, and optimize processes.

InteractX Windows

Windows based SCADA & HMI software

Information Anywhere! InteractX leverages your investment in machine level HMIs to make development of Supervisory applications faster and easier. InteractX can connect directly to Interact Xpress screens and data, allowing you to re-use your machine level application elements at the Supervisory level. This can save up to 80% of Supervisory application development time. It is faster and easier to develop than any other SCADA package!
