Description
Unwavering accuracy
- High accuracy – Resolution 0.01°
- Measuring range from 0… to 360° or ±85°
- High protection class of IP67 / IP69k
- Working temperature range -40 °C to +85 °C
- Stack mounting possible for redundancy
- Interfaces: Analog, CANopen, Modbus, SAE J1939
Measuring inclination angles in the range from 0 to 360°
Find the right inclinometer for your application, for example for measuring the installation angle of the placing boom in construction machinery.
The sensors are based on the proven capacitive measuring principle (MEMS). 1x M12 plug or 2x M12 plug variants are available. E1 and UL certified.
1-dimensional inclinometer
- Preset and teach function
- Measuring range 0 to 360°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 1.0°
1-dimensional inclinometer
- Parameterizable filter setting
- Measuring range 0 to 360°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.2°
1-dimensional inclinometer
- Parameterizable filter setting
- Measuring range 0 to 360°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.2°
1-dimensional inclinometer
- Parameterizable filter setting
- Measuring range 0 to 360°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.2°
1-dimensional inclinometer
- Teach function
- Measuring range 0 to 360°
- High protection class IP69k
- Resolution ≤ 0.14°
- Repeat accuracy ≤ 0.1% of measuring range
Measuring inclination angles in the range from ±85°
Find the right inclinometer for your application, for example for vehicle leveling or for use in solar systems.
The sensors are based on the proven capacitive measuring principle (MEMS). 1x M12 plug or 2x M12 plug variants are available. E1 and UL certified.
2-dimensional inclinometer
- Preset and teach function
- Measuring range ±85°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.5°
2-dimensional inclinometer
- Parameterizable filter setting
- Measuring range ±85°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.4°
2-dimensional inclinometer
- Parameterizable filter setting
- Measuring range ±85°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.4°
2-dimensional inclinometer
- Parameterizable filter setting
- Measuring range ±85°
- High protection class IP69k
- Resolution 0.01°
- Accuracy typical ± 0.4°
2-dimensional inclinometer
- Teach function
- Measuring range ±85°
- High protection class IP69k
- Resolution ≤ 0.05°
- Repeat accuracy ≤ 0.1% of measuring range
