• Time savings
• Maintenance-free
• Suitable for all conductor types

• Reliability for all applications
• Long-term contact quality – independent of operator skill

In various industrial applications and modern building installations, TOPJOB® S Rail-Mount Terminal Blocks offer more than just reliable electrical connections. The comprehensive line of through and function terminal blocks for conductor cross-sections from 0.14 to 25 mm2(26–4 AWG) offers a variety of advantages.

Advantages:

• Universal Push-in CAGE CLAMP® Connection Technology for all conductor types
• Push-in termination of solid and stranded conductors, as well as fine-stranded conductors with ferrules
• The right solution for all commoning tasks: continuous, adjacent, step-down, vertical jumpers and more
• Continuous, multi-line marking strips for time- and cost-saving marking
• Industry-leading safety reserves: a single rail-mount terminal block system for virtually any application in the world

The high-current, rail-mount terminal blocks with POWER CAGE CLAMP apply spring pressure to connect conductors up to 185 mm2 (350 kcmil). They are available as 35, 50, 95 and 185 mm2 (2, 1/0, 4/0 AWG; 350 kcmil) terminal blocks. Versions are available for both DIN-rail mounting and direct mounting onto the plate via mounting flanges.

Advantages:

• For all applications: energy-intensive industries including machinery and equipment manufacturing, as well as energy production
• Also suitable for harsh conditions: heat- and cold-resistant
• Ex e II approvals (185 mm2/350 kcmil pending)
• Easy to use: side-entry conductor insertion and locking tab for easy wiring
• Fast termination: no time-consuming preparation – no ring terminals or ferrules required

A compact design makes Mini Rail-Mount Terminal Blocks ideal for work in tight spaces. Various mounting and actuation variants are also available for maximum flexibility, so you can choose your Mini terminal blocks based on use and convenience. Thanks to spring pressure connection technology, they are also suitable for vibration-proof connections and can be used in junction boxes of three-phase motors, for example.

• Save space: compact design with full functionality
• Reliable and secure: The proven spring pressure connection technology makes connections vibration-proof.
• Flexible mounting options: Mini Rail-Mount Terminal Blocks can be secured on DIN-15 or DIN-35 rails and mounting plates with a snap-in mounting foot or mounting flange.
• Quick and easy operation: For Mini Rail-Mount Terminal Blocks, you can choose between a push-button and operating slot.
• Easy commoning, marking and testing

The X-COM®S-SYSTEM is available in two different cross-sections (2020 and 2022 Series). It is compatible with our TOPJOB® S Rail-Mount Terminal Blocks and the wide range of accessories from the TOPJOB® S Rail-Mount Terminal Block family.

Advantages:

• Terminate conductors up to 1.5 mm2 (16 AWG) in a terminal block width of just 3.5 mm (0.138 inch) and up to 4 mm2 (12 AWG) in a width of just 5.2 mm (0.205 inch)
• Push-in CAGE CLAMP® for fast wiring
• Push-in termination of solid and stranded conductors, as well as fine-stranded conductors with ferrules
• Prevent mismating by coding groups with the same pole numbers
• Secure female plugs via locking levers and strain relief plates

The rail-mount terminal block program with proven CAGE CLAMP® Connection Technology has the right terminal block for any application: fuse, disconnect/test, diode and LED terminal blocks, pluggable terminal blocks – even rail-mount terminal blocks for wiring sensors and actuators.

Advantages:

• Multilevel terminal blocks: Double- or triple-deck terminal blocks save space
• CAGE CLAMP® connections: tried-and-tested billions of times
• Multifaceted, individual commoning options via push-in type jumper bars, step-down jumpers, staggered jumpers, vertical jumpers, etc.
• Circuit identification via WMB markers
• Easy testing via pluggable and modular test plug adapters, as well as test plugs

Mini Rail-Mount Terminal Blocks are ideal for space-limited applications and small conductor sizes. With the proven CAGE CLAMP® technology, these terminal blocks provide vibration-proof and reliable connections.

Advantages:

• Require minimal enclosure space
• Mounting on DIN-15 or DIN-35 rail
• Light gray versions for Ex e II applications
• Easy commoning, marking and testing
