Dedicated HMI Touchscreen

This new, affordable Human-Machine Interface (HMI) solution fully leverages the wide availability of web browsing software to enable distributed HMI software, remote support and application sharing on the Internet and IP Networks Interact Xpress HMI applications are developed, edited, published and run in an HMI that is a Web Server, allowing users and OEMs to easily publish upgrades and applications to any global location with an Internet connection and a web browser. Interact Xpress combines a rich, graphical runtime interface with HMI development tools that can be accessed from either the HMI panel or any PC running Internet Explorer®.

Interact Xpress software is pre-installed and bundled with CTC’s new XPR PowerStation hardware, which is designed to optimize the performance, storage and connectivity features of Xpress HMI. This NEMA4/4X-rated family of CE-based workstations is available in either an embedded no display unit or with a 6″, 8″, 10″ and 15″ TFT touchscreen display models. All models feature embedded fanless CPU technology, 256MB DRAM and a full range of standard features such as CompactFlash storage, 2 USB ports, 2 RS-232 and RS232/422/485 ports and a 100BaseT Ethernet port. With 512 MB of Compact Flash storage, XPR models use nonrotating storage media for high system reliability. And like all CTC Powerstations, these units are quality tested to endure more harsh conditions in a day than most operator stations see in a lifetime. That’s why we’re able to offer an industry-leading, 2-year limited warranty with free phone-based technical support for all of our products.

  • Real time trend display
  • New improved security in Version 2.x
  • Sophisticated graphics look and feel with ease of development
  • Integrated Web Publishing capability for distributed applications
  • No version control issues with Web published development
  • Applications can be served, created and edited online from any PC with Internet Explorer
  • Available offline, development software allows work on applications when a live Internet connection is not available
  • Advanced security for single or multi-user applications
  • Tools for historical alarm data
  • Capacity for complex graphics and animations
  • Standard Ethernet port for both networking and controller communications
  • More than 35 device communication drivers
  • Color depth to 262,144 colors
  • XPR PowerStation industrially hardened hardware with steel backshell construction
  • Industry-leading 2-year warranty
